Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System

Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System

Detailed Product Description

Company Profile
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 0
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 2
Product Description


Our factory can customize fully automatic packing machine, Semi automatic packing machine, jumbo bag packing machine, robot palletizer, collaborative robot, industrial robot, conveyor and other equipments.

This is a very practical packing machine on the market at present,with reasonable structural design to ensure packaging efficiency and product quality.The compact body size save space and is suitable for a variety of production enviroments.at the same time,the machine is easy to operate,easy to maintain,so that you can easy to control.

Workflow:Giving the bag (loading the bag) → automatically clamps the bag→ material is automatically
quantitatively weighed and filled into bags→ automatic bag release /bag holding/bag transfer→ automatic label feeding /folding /or
heat sealing/or sewing→ entering the next process

Advantage: -Wide packing range, high precision, it can match well with conveyor and sewing/sealing machine. -Products using imported sensor, pneumatic actuator, easy maintenance and non-pollution. -The main material body is carbon steel, with painted plastic. And material contact part can be 304 Stainless Steel or 316 Stainless Steel

Selection Recommendations

Fully Automatic Packaging Machine: Ideal for large-scale production and high-efficiency requirements.

Semi-Automatic Packaging Machine: Suitable for small-batch, multi-variety production or scenarios requiring high packaging precision.

Jumbo Bag Packaging Machine: Designed for large-capacity bulk material packaging, commonly used in chemical, building material, and mining industries.

If you have specific material or industry requirements, feel free to discuss further so we can recommend the most suitable equipment!
Details Images
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 4
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 6
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 8
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 10
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 12
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 14
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 16
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 18
Specification
Material
SS304  3mm Contact parts
Gross Weight
1000kg
2Packing Capacity
15-40 bags/h
Weighing Range
200-2000kg or Customized
Quantify Precision
±0.2%
Power
0.5kw
Power Supply
AC 220V/380V 50 HZ 1P/3P Customized
Air Source
0.4~0.6MPa 0.36m³/min
Application Materials
Applicable for packing granular or particle materials such as chemistry, fertilizer, grain, rice, sand, wood pellets, animal feed,urea, phosphate, PP, PE granules, construction materials
Application Materials
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 20
Packing & Delivery
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 22
Why Choose Us
Automatic Weighing FIBC Filling Bulk Jumbo Ton Bag Packaging Machine 200KG 500KG 1000KG Big Bag Packing Machine Ton Bag System 24
FAQ
Q1: Are you factory or trading company? A1: We are the factory, we doing this line for more than 10 years. Q2: How to choose suitable packaging machine? A2: Need to provide your material pictures and requirements, such as packaging speed, packaging weight, bag type and bag size. Q3: How to ensure the quality of the machine? A3: We usually delivery the machine after successful inspection in our factory. We have our own quality control department,beforethe delivery we have to running the machine for three days without problem. You can send us your materials and we will make video as long as you want. Or you can arrange a third-party inspection agency. Q4: How to install the equipment? A4: We will provide manuals and detailed videos to help customer install machine. If necessary, we will send technicians to the customer's factory to assist, and the customer only needs to pay. Q5: What's your payment way? A5: T/T by our bank account directly, or by Alibaba trade assurance service, or by West Union, or L/C.
